Motorola MOTOTRBO R5

Frequency bands:
VHF, UHF

Frequency Range:
VHF: 136-174 MHz
UHF: 400-512 MHz

Number of Channels/Groups/Zones:
Limited Keypad Model: 256 Channels/ 50 Zones
Non-Keypad Model: 64 Channels/ 4 Zones

Power Output:
VHF: 5 Watts
UHF: 4 Watts

Channel Spacing:
12.5 / 25 kHz

Battery Life

MOTOTRBO R5 with 3200 mAh battery (PMNN4889)
Digital / Analog Battery Life: 32 / 24 hrs

MOTOTRBO R5 with TIA4950 3200 mAh battery (PMNN4890)
Digital / Analog Battery Life: 32 / 24 hrs

MOTOTRBO R5 with 2200 mAh Slim battery(PMNN4888))
Digital / Analog Battery Life: 21.5 / 16 hrs

Dimensions H x W x D (with standard battery)

MOTOTRBO R5 with 3200 mAh battery (PMNN4889)
4.82 x 2.2 x 1.6 inches

MOTOTRBO R5 with TIA4950 3200 mAh battery (PMNN4890)
4.82 x 2.2 x 1.6 inches

MOTOTRBO R5 with 2200 mAh Slim battery(PMNN4888)
4.82 x 2.2 x 1.37 inches

Weight (with standard battery)

MOTOTRBO R5 with 3200 mAh battery (PMNN4889)
11.2 oz

MOTOTRBO R5 with TIA4950 3200 mAh battery (PMNN4890)
11.7 oz

MOTOTRBO R5 with 2200 mAh Slim battery(PMNN4888))
10 oz

Operating temperature
-22 °F to 140 °F

Mil spec

IP Standards
IP67
